Self Centering Vise 120x90x83mm, System 3R Compatible
Precision self centering vise designed for 4th and 5th axis CNC machining, EDM workholding, and palletized fixture systems. Built from hardened chrome steel with 48–52 HRC hardness, this System 3R compatible vise provides ±0.005mm repeatability, 70mm max clamping width, 4000N clamping power, and 30Nm max torque. Its 120x90x83mm body supports strong part holding, accurate centering, and repeatable precision machining setups.
Read more
Self Centering Vise 120x90x97.5mm, System 3R Compatible
Precision self centering vise designed for 4th and 5th axis CNC machining, EDM workholding, and palletized fixture systems. Built from hardened chrome steel with 48–52 HRC hardness, this System 3R compatible vise provides ±0.005mm repeatability, 46mm max clamping width, 400N clamping power, and 30Nm max torque. Its 120x90x97.5mm body supports stable clamping, accurate part centering, and repeatable precision machining setups.
Read more
Self Centering Vise 91x54x64mm, System 3R Compatible
Precision self centering vise designed for 4th and 5th axis CNC machining, EDM workholding, and compact palletized fixture systems. Built from hardened chrome steel with 48–52 HRC hardness, this System 3R compatible vise provides ±0.005mm repeatability, 62mm max clamping width, 300N clamping power, and 30Nm max torque. Its 91x54x64mm body supports stable clamping, accurate part centering, and repeatable precision machining setups.
Read more
Mini Self centering vise System 3R 60X54mm-25mm clamping
Self-centering vise 60X54mm on System 3R 54 or 70mm macro pallet. RHS mini self-centering vise is 25mm clamping mounts directly on System 3R parts. Special holder to clamping small weight workpiece. Use a regular handle to threading the side screw to lock the workpiece and centering on the holder.
| SPECIFICATIONS | |
| Size | 60X54X52mm |
| Repeatability | within 0.005 |
| Material | High grade steel 48-52HRC |
| Max Clamping | 25mm |
| Torque | 20NM |
| Weight | 1kg |
$810.00
Add to cart
Self Centering Vise 60x54x61.5mm, System 3R Compatible
Precision self centering vise designed for 4th and 5th axis CNC machining, EDM workholding, and compact palletized fixture systems. Built from hardened chrome steel with 48–52 HRC hardness, this System 3R compatible vise provides ±0.005mm repeatability, 31mm max clamping width, and 200N clamping power. Its 60x54x61.5mm body supports accurate small-part positioning, repeatable fixture changes, and stable precision machining setups.
Read more
70mm Precision Self Centering Vise on Compatible 3r Pallet
70mm Precision Self Centering Vise on 3R compatible Pallet
Mini Precision 5 Axis Self Centering Vise on 3r pallet 70mm 3R-601.7E-P. Clamping Maximum Work Piece Size 70mm. Double Self Centered with Repeating Accuracy of 0. for Vertical and Horizontal Processing Machine.
$1,125.00
Add to cart
Self Centering Vise On 3Refix MacroMagnum Pallet,4.725 Inch workpiece
5 Axis Machining Self Centering Vise On 3Refix MacroMagnum Pallet,4.725 Inch workpiece
System 3R equivalent Macro Magnum Self Centering Vise 4.725 Inch. Maximum Size Work Piece is 120mm and is useful because of high accuracy & precision. Stainless Steel Construction with 4.725" Maximum work piece. Bidirectional self centering reputability of .005MM. It comes Mount and Center on Macro Magnum Pallet. Suitable for vertical and horizontal precision processing machine. Ready to Run.stp file available on request.
$1,825.00
Add to cart
System 3R Self Centering Compatible Vise on 3R pallet
System 3R Self Centering Compatible Vise on 3R pallet
Mini Precision 5 Axis Self Centering Vice. Clamping Maximum Work Piece Size 2.75" or 70mm. Double Self Centered with Repeating Accuracy of 0. for Vertical and Horizontal Processing Machine. Comes pre-mounted on 54mm Precision cast 3R-651.7E-P Macro pallet.| SPECIFICATION | |
| Application | For 5 axis cnc machining use |
| Clamping | Maximum Work Piece Size 2.75" |
| Material | Stainless Steel |
| Accuracy | 0.01mm |
| Version | Pre- mounted on 54mm 3R-651.7E-P Macro pallet |
$925.00
Add to cart
System 3R Compatible Self Centering Vice
Designed for cutting 3-axis or 5-axis machiningSelf centering feature is great for precision work holding for your fussiest projectsComes with 3R 70mm pallet base or Erowa ITS system base to easily amount to your System 3R or Erowa ChucksIf other bases are require, please let us know as we can customize them
Read more
