3R COMPATIBLE 3R-651E-P PALLET 54 MM
Hardened with clearance holes for four fixing
– Adapted for automatic changing.
– Supplied in sets of eight.
– Parallel-ground top and bottom faces.
System 3R OEM
Manual chuck adapter Macro-Macro
EROWA ITS ER-028471 Compatible Angle clamping unit
Manual ITS Chuck on which angles can be set continuously from 0 to 90°. Application in EDM and WEDM.
This chuck makes it easyer to machine lateral gatings in injection molds. Various angles may be produced with standard electrodes.
EROWA ER-010723 Checking Pin Hardened Ground Alignment of radial, axial and angular position of ITS chucks.
100% EROWA Compatible
SPECIFICATION NAME ER-20 COLLECT HOLDER SIZE 52X53X78mm MATERIAL STAILNLESS STEEL 420 48-52HRC INCLUDED Φ 12 COLLET 1pcs TOLERANCE AFTER ASSEMBLY COPPER ELECTRODE. CONNECTIVITY TOLERANCE ± 0.015mm
EROWA ER-037970 ITS Chuck 100 Pneumatic Incl CNC Plate For receiving pallets ø 115 / ø 148, electrode holders, pallets PM56, PM60 and PM85 Precise
100% EROWA Compatible EDM Tooling
EROWA ER-010755 Spigot Drawbar Pullstud Flushing F/M EDM for flushing
100% EROWA COMPATIBLE
System 3R COMPATIBLE 3R-610.21-S CNC Manual chuck Macro
100% SYSTEMS 3R COMPATIBLE
Rapid Holding systems covers all the applications of palletizing and holding Workpieces or Electrodes EDM Tooling and in any manufacturing technology, Milling, EDM, WireEDM or Laser. Tooling is the first step to increase productivity and the base for the next step: Automation! With EDM Tooling experence the Rapid Holding Systems has the strength of the company is significantly enforced and the wide range of our product portfolio allows our customer to choose the right product.
